Pickup pattern: Omnidirectional
Frequency range: 20 Hz - 94 kHz
Sensitivity: 45,2 mV/Pa / -26,9 dB re 1 V/Pa
Signal-to-noise ratio: 74 dB A
Maximum sound pressure level: 115 dB SPL
Output impedance: 35 Ω
Operating voltage: 12 V - 48 V
Power consumption: 4 mA
Length: 90 mm
Diameter: 22 mm
Weight: 70 g
Surface finish: sandblasted stainless steel
Functional principle: low frequency electret condenser microphone
Due to its inaudible frequency response, the SD102 is perfectly suited for sound design applications.
We recommend it for main microphone systems as well.
Take a look at our audio files.
